68"LCD Full Screen
Product Introduction | 1. Support real-time management and release on mobile, iPad and PC | |
2. Support remote upgrade of advertising player software version and OTA upgrade | ||
3. Support the advertising machines in the same group can be played synchronously and the interval is less than 500ms synchronization | ||
4. Support the mobile phone to remotely set the properties of the advertising player, control the volume,rotation angle, time zone, turn off and turn on the advertising player | ||
5. Support remote monitoring of the network status, system status and hardware status of the player, and monitor the content of the advertising playeradvertising | ||
6. Support the needs of multiple forms of rolling subtitles and bullet screens, the font, size and subtitles and bullet screens can be editedcontent of | ||
7. Scheduling supports multiple priority levels, and supports shim/normal/interrupt/emergency message priority | ||
8. Scheduling supports multiple recurring modes, recurring by day/week/month | ||
9. It can support multiple media such as video/picture/marquee/subtitle/RSS/ component/ppt/pdf | ||
10. Support self-built template mobile phone one-key call to modify at any time | ||
Display parameters | Model | 68" |
Panel Type | a-Si TFT-LCD | |
Display area | 467×1649(H×V)mm | |
Display Proportion | 32:9 | |
Resolution | 1080*3840 | |
Display Color | 16.7M | |
Dot Pitch | 0.1625(H)*0.4875(V) | |
Brightness | 500CD | |
Contrast | 1000:1 | |
Viewing angle | 178° | |
Response Time | 8ms | |
Refresh Rate | 60Hz | |
Manual Language | Chinese/English | |
System Parameters | CPU | ARM Cortex-A17 |
DDR | 2G DDR3 | |
Flash | 16G EMMC | |
Wifi | 2.4G WIFI | |
802.11b : DQPSK, DBPSK, CCK | ||
802.11g/n : 64-QAM,16-QAM, QPSK, BPSK | ||
Interface support | TF Card×1/USB×2/RJ45×1 | |
System Version | Android 7.1 | |
Power | Input Voltage | ~AC 100-240V 50/60Hz |
Maximum power consumption | 140W | |
Standby power consumption | ≤0.1W(Board only) | |
Other | storage temperature | -20--60° |
Amplifier power | 2×10W | |
Product Size | 694*510*24mm | |
Product Weight | 45KG |
